Heki 2 De Luxe Caravan Rooflight Parts List & Technical Drawings

1. TITLE

Heki 2 De Luxe Caravan Rooflight Parts List & Technical Drawings

2. DESCRIPTION

Download the Heki 2 De Luxe Caravan Rooflight Parts List and Technical Drawings, a 4-page PDF reference covering the components, replacement part numbers and exploded diagrams for the HEKI II DELUX / Heki 2 De Luxe rooflight. The document specifically identifies the model as “HEKI II DELUX” and includes a technical drawing for the Heki 2 De Luxe. Heki 2 De Luxe parts list (As H…

This Heki 2 De Luxe parts manual is useful for caravan owners, repairers and technicians who need to identify individual rooflight components, locate replacement part numbers or understand how the exterior frame, acrylic dome and interior frame assemblies fit together.

What's covered:

• Heki 2 De Luxe technical drawing and dimensions
• Roof aperture and dimensional information
• Exterior frame exploded diagram
• Exterior frame without fixings
• Brush profiles
• Mounting kits for different roof thicknesses
• Closing brackets for the operating bar
• Acrylic dome exploded diagram
• Glazing panel
• Top hinge and operating bar
• Lift handles
• Gas struts
• Cap covers
• Interior frame components
• Complete flyscreen
• Complete blind
• Spring motor
• Vent profiles/light covers
• Socket and cables
• Individual replacement part numbers

The exterior-frame section includes mounting kits covering 25–32 mm, 32–39 mm, 39–46 mm, 46–53 mm and 53–60 mm thicknesses, along with the relevant part numbers. Heki 2 De Luxe parts list (As H…

The acrylic-dome diagram identifies the glazing panel, top hinge, operating bar, lift handles, gas struts and cap covers. Heki 2 De Luxe parts list (As H…

The interior-frame section covers components including the flyscreen, blind, spring motor, cream and grey vent profile/light covers, socket with cables and complete interior frame. Heki 2 De Luxe parts list (As H…

Model compatibility:

This document is specifically for the Heki 2 De Luxe / HEKI II DELUX rooflight. It is a parts list and technical drawing reference rather than an operating or installation instruction manual.

Please note: This listing is for a digital PDF parts list and technical drawing document only. No physical rooflight or replacement parts are supplied.
