Sargent AS250 Remote Control Alarm System Instruction Manual

Download the Sargent AS250 Remote Control Alarm System Instruction Manual, covering the operation, programming, adjustment and installation of the AS250 vehicle alarm system.

The AS250 is a one-piece remote control alarm with the control circuitry and alarm siren housed in the same casing. It supports current sensing, shock sensing and electrical contact switching, with provision for an optional ultrasonic movement detector. The system also includes functions such as panic alarm, selectable siren sounds, indicator flashing, battery backup, override key switch and vehicle locator. AS 250 remote control alarm sys…

This 8-page PDF manual is useful for owners who have lost their original Sargent AS250 handbook, acquired a vehicle without its alarm instructions, need help operating or programming the system, or require the original installation and wiring guidance.

What's covered:

• AS250 alarm system introduction and features
• Arming and disarming the alarm
• Two-button key fob transmitter controls
• Arming with the shock sensor disabled
• Panic alarm operation
• Silent arm and disarm
• Vehicle locator function
• LED status and intrusion indicators
• Audible chirp and direction-indicator signals
• Override key switch operation
• Automatic rearming
• Warn Away facility
• Alarm triggering and automatic reset
• Key fob transmitter battery replacement
• Alarm fuse replacement
• Programming replacement or additional key fob transmitters
• Shock sensor sensitivity testing and adjustment
• Siren tone selection
• Alarm system installation
• Mounting the AS250 alarm unit
• LED status indicator installation
• Bonnet and boot pin-switch installation
• Backup battery installation
• Main wiring and connector information
• RF antenna positioning
• Optional accessories and ultrasonic movement detector information

The manual provides detailed operating guidance for the AS250 remote control. The key fob can be used for normal arm/disarm operation, disabling the shock sensor, activating the panic alarm, silent operation, locating the vehicle, programming shock sensitivity and selecting the siren tone. AS 250 remote control alarm sys…

A dedicated programming section explains how to programme the AS250 to recognise up to two transmitters, making it useful when replacing a key fob or adding a second remote. It also explains how to adjust the shock sensor through eight sensitivity levels. AS 250 remote control alarm sys…

The manual contains full installation instructions as well as user operating information. These include safety precautions, mounting the alarm system, installing the LED status indicator and bonnet/boot pin switches, fitting the backup battery and connecting the alarm wiring. The instructions state that the AS250 is intended for negative-earth vehicles. AS 250 remote control alarm sys…

Model compatibility:

This manual specifically covers the Sargent AS250 Remote Control Alarm System. The document is identified as AS250 Manual Issue 2, dated 14/02/06. AS 250 remote control alarm sys…

Optional accessories described in the manual include a power-lock door interface, spare/second key fob transmitter, CS-18S ultrasonic movement detector and garage door module. AS 250 remote control alarm sys…

Please check that your alarm system is marked AS250 before purchasing to ensure this is the correct Sargent alarm manual for your equipment.

Please note: This listing is for a downloadable PDF manual only. No alarm, key fob, sensor, wiring, battery or other physical equipment is supplied.
